WMTCNC precision lathe machine D250V bench mini lathe price

Overview

Basic Info.

Model NO.	D250V
Power Source	Manual
Controlling Mode	Artificial
Automatic Grade	Manual
Setting Mode	Table
Precision	Precision
Certification	GS, CE, ISO 9001
Condition	New
Spindle bore	26mm
Distance between centers	550/750mm
N.w/G.w	125/132kg, 135/142kg
Spindle speed	Variable: 50-2500rpm
Model	D250V
Max. swing over bed	250mm
Machine Type	mini lathe machine
Transport Package	Plywood Case
Specification	1150(1350)*480*500mm
Trademark	WMTCNC
Origin	China, Anhui
HS Code	8458190000
Production Capacity	100 Sets/Month

Product Description

Product Description
WMTCNC D250V mini metal lathe machine main features:
1. Widely used, simple operation, and a wide range of processing.
2. Strong power, maintenance-free DC motor.
3. After quenching and precision grinding of cast iron bed.
4. High precision, quenching spindle.

Model	D250V
Max. swing over bed	250 mm
Max. swing over cross slide	150mm
Max. compound slide travel	70mm
Max. carriage slide travel	135mm
Max. carriage travel	450/650mm
Distance between centers	550/750mm
Width of bed	135mm
Spindle bore	26mm
Spindle taper	MT4
Spindle speed	Variable: 50-2500rpm
Range of metric threads	21 kinds:0.2-4mm
Range of imperial threads	8 kinds:8-56T.P.I
Max. travel of tailstock quill	60 mm
Tailstock taper	MT2
Motor power	750w
Machine size(L×W×H)	1150(1350)×480×500mm
Packing size	1220(1400)×560×560mm
N.w/G.w	125/132kg, 135/142kg

Detailed Images

Company Profile

FAQ

Q1: How is the warranty?A1: Warranty time is 13 months after BL date.Q2: Can we visit your factory before order?A2: Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking. Q3: Do you have a stock?A3: Sorry, most of our machines don't have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.Q4: What's the MOQ?A4: One set only.Q5: How about your quality?A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.Q6: Do you have professional engineers?A6: Yes, we have professional engineers and designers. We can provide OEM services.Q7: Can you provide customized machines?A7: Yes, we can design and manufacture according to your specific requirements.
