WMTCNC precision lathe machine D250V bench mini lathe price
Basic Info.
Model NO. | D250V |
Power Source | Manual |
Controlling Mode | Artificial |
Automatic Grade | Manual |
Setting Mode | Table |
Precision | Precision |
Certification | GS, CE, ISO 9001 |
Condition | New |
Spindle bore | 26mm |
Distance between centers | 550/750mm |
N.w/G.w | 125/132kg, 135/142kg |
Spindle speed | Variable: 50-2500rpm |
Model | D250V |
Max. swing over bed | 250mm |
Machine Type | mini lathe machine |
Transport Package | Plywood Case |
Specification | 1150(1350)*480*500mm |
Trademark | WMTCNC |
Origin | China, Anhui |
HS Code | 8458190000 |
Production Capacity | 100 Sets/Month |
Product Description
Product DescriptionWMTCNC D250V mini metal lathe machine main features:
1. Widely used, simple operation, and a wide range of processing.
2. Strong power, maintenance-free DC motor.
3. After quenching and precision grinding of cast iron bed.
4. High precision, quenching spindle.
Model | D250V |
Max. swing over bed | 250 mm |
Max. swing over cross slide | 150mm |
Max. compound slide travel | 70mm |
Max. carriage slide travel | 135mm |
Max. carriage travel | 450/650mm |
Distance between centers | 550/750mm |
Width of bed | 135mm |
Spindle bore | 26mm |
Spindle taper | MT4 |
Spindle speed | Variable: 50-2500rpm |
Range of metric threads | 21 kinds:0.2-4mm |
Range of imperial threads | 8 kinds:8-56T.P.I |
Max. travel of tailstock quill | 60 mm |
Tailstock taper | MT2 |
Motor power | 750w |
Machine size(L×W×H) | 1150(1350)×480×500mm |
Packing size | 1220(1400)×560×560mm |
N.w/G.w | 125/132kg, 135/142kg |
Q1: How is the warranty?A1: Warranty time is 13 months after BL date.Q2: Can we visit your factory before order?A2: Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking. Q3: Do you have a stock?A3: Sorry, most of our machines don't have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.Q4: What's the MOQ?A4: One set only.Q5: How about your quality?A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.Q6: Do you have professional engineers?A6: Yes, we have professional engineers and designers. We can provide OEM services.Q7: Can you provide customized machines?A7: Yes, we can design and manufacture according to your specific requirements.
